Technical Details
Outer Thread (mm) : M 12 x 1.5
Number of Connectors : 3
Weight : 2,586 g
Capacity : 700 ml
Left-/right-hand drive vehicles : for left-hand drive vehicles
Length : 130 mm
Width : 80 mm
Height : 121 mm
Pressure [bar] : 280 bar400 bar
Overflow Pressure : 400 bar

Technical Details
Outer Thread (mm) : M 12 x 1.5
Spanner Size : 22
Weight : 2,622 g
Capacity : 700 ml
Left-/right-hand drive vehicles : for right-hand drive vehicles
Length : 130 mm
Width : 80 mm
Height : 135 mm
Pressure [bar] : 280 bar
Overflow Pressure : 370 bar

Technical Details
Length (mm) : 450
Outer Thread (mm) : M 12 x 1.5
Stroke (mm) : 280 mm
Bore Ø : 42 mm
Weight : 6,468 g

Technical Details
Pipe : 60 mm
Weight : 8,284 g
Thread Size : M12 x 1,5
Length : 694 mm
Bore Ø : 42 mm
Stroke : 320 mm
Pressure [bar] : 250 bar

Technical Details
Length (mm) : 580
Outer Thread (mm) : M 14 x 1.5
Diameter (mm) : 50
Stroke : 295 mm
Weight (kg) : 6.388
Bore Ø : 42 mm
Pipe : 42 mm
Pressure [bar] : 250 bar

Technical Details
Length (mm) : 643
Number of Ports : 2
Pipe (mm) : 42
Stroke (mm) : 295
Weight : 4,150 g
Inner Diameter 1(mm) : 42
Thread Size : M12 x 1,5

Technical Details
D1 : 38 mm
Thread Size 1 : M 12 x 1.5
D2 59 mm
Weight : 7,655 g
Thread Size 2 : M14 x 1,5
Pressure [bar] : 400 bar
Stroke : 319 mm
Bore Ø 2 : 33 mm
Bore Ø 1 : 25 mm
Length : 502 mm

Technical Details
Length (mm) : 648 , 960
Outer Thread (mm) : M 14 x 1.5, M 12 x 1.5
Stroke (mm) : 330
Weight (kg) : 9.750
